How to install the distance of solar street lights

2023-08-10 15:28:08

The installation distance of solar street lights mainly depends on the design of the street lights and the requirements of the area to be illuminated. The following are the factors that should be considered when installing solar street lights in general:

Lighting requirements: Firstly, determine the lighting range and brightness of the solar street lamp you want. This depends on the purpose of the street light and the required lighting level. Different applications may require different types and powers of solar street lights. Make sure to choose streetlights that are suitable for your desired lighting range.

Installation height: The installation height of solar street lamps can also affect the lighting range and brightness. Generally speaking, a higher installation height can expand the lighting range, but it will reduce the lighting intensity. Determine the appropriate installation height based on the required lighting effect.

Installation location: Choosing an appropriate installation location is very important. Ensure that solar panels receive sufficient sunlight and avoid any potential obstacles such as buildings, trees, or other obstacles as much as possible. In addition, considering the efficacy and safety of street lights, install them in appropriate locations to ensure that lighting needs are met.

According to the construction drawings and on-site geological survey, the installation position of street lights should be determined based on the distance between street lights of 20-50 meters in areas without shading at the top of the street lights. Otherwise, the installation position of street lights should be adjusted appropriately.

street lights to ensure sufficient lighting

The road width is about 3-4 meters. Light pole 3-4 meters. 15-20 watt LED lamp holder, installation distance should be 20-25 meters;

2. The road width is about 5-7 meters, and the lamp pole is 5-7 meters. The LED lamp holder is 30-50 watts, and the installation distance should be 30-40 meters;

3. The road width is about 8-12 meters, and the lamp pole is 8-12 meters. The installation distance should be 30-50 meters with LED lamp caps of 50-120 watts.

street lights to ensure sufficient lighting

Installation spacing: If you need to install multiple solar street lights, you need to consider the installation spacing between them. Based on lighting requirements and design requirements, determine the optimal spacing between street lights to ensure sufficient lighting coverage for the entire area.

Please note that the above suggestions only provide general guidance, and the specific installation distance should be evaluated based on the actual situation and requirements. For specific installation plans, it is recommended to consult professional solar street lamp suppliers, designers, or installation personnel for more accurate advice and guidance.

Please contact us to provide you with a lighting plan.
