Home Integrated Solar Garden Lights Ik10 Outdoor Waterproof LED Solar Lamp Driveway Path Lighting Square Garden Solar Pillar Lamp
Hot Products
solar light
Products
Outdoor Driveway Pathway Lighting
Ik10 Outdoor Waterproof LED Solar Lamp Driveway Path Lighting Square Garden Solar Pillar Lamp Ik10 Outdoor Waterproof LED Solar Lamp Driveway Path Lighting Square Garden Solar Pillar Lamp Ik10 Outdoor Waterproof LED Solar Lamp Driveway Path Lighting Square Garden Solar Pillar Lamp Ik10 Outdoor Waterproof LED Solar Lamp Driveway Path Lighting Square Garden Solar Pillar Lamp Ik10 Outdoor Waterproof LED Solar Lamp Driveway Path Lighting Square Garden Solar Pillar Lamp
Ik10 Outdoor Waterproof LED Solar Lamp Driveway Path Lighting Square Garden Solar Pillar Lamp

  • Model No. :

    LR-360IK

  • LED brand :

    LEADRAY

  • LED Power :

    0.2W/led

  • Solar Panel Power :

    6.2 Watts 5V

  • Battery Type :

    3.2V 12AH 38.4WH

  • Infrared senor :

    NO
Contact Us
description

Outdoor lighting


Product name：Leadray -LR-360IK
Lighting：1.2W 280lm
Light head diameter：275mm
Fixture material：Aluminium die casting + PC
Fixture color：Anthracite grey RAL 7016
CRI：>82
IP & lK rate：IP65 & IK10
CCT range：2200K~6000K
Beam angle：120 degrea

Leadray solar bollard light offers a futuristic design with a five-year warranty for public space outdoor lighting applications where
the benefits of IK10 vandal resistance are required. LifePO4 battery combined with an intelligent lighting program provides 100%
power up to 280 lm for 4 hours before changing to 30% power of full production to 100% when the PIR sensor is triggered. It
ensures up to four nights of lighting on a single full charge of the battery. The mission of Leadray is to comply with the
requirement of the Dark Sky Association by limiting the upward light waste ratio (UWLR) to <1%. Limiting upward light reduces
environmental light pollution and protects the view of our night sky for all.

We also offer the Leadray Solar bollard light in a wildlife-friendly version retaining all the features of the original product.
Wildlife-Friendly lighting is specifically designed to minimize the ecological impact on animals and insects.

Outdoor lighting


Battery type：LiFePO4 32700 6000mA 3.2V
Battery capacity：38.4WH 3.2V
Battery lifetime:6000 cycles @ D.0.D 80%
Charge time:4.5 hours
Discharge time:>36 hours
Working temp:-15°C~ 60°C
Battery autonomy:3 -4 days with motion sensor

Outdoor lighting



IK10 Dark Sky Friendly Solar Bollard

IK10 Dark Sky Friendly Solar Bollard
The mission of MUSE is to comply with the requirement of the Dark Sky Association by limiting the upward light waste ratio (UWLR)
to <1%. Limiting upward light reduces environmental light pollution and protects the view of our night sky for all. By using
2700K/3000K led chips, it provides a friendly environment to animals in the dark to protect their eyes from LED lights. MUSE is a

solar bollard light for gardens, walkways public parks as well as ecologically sensitive.


Lamp Sizes：275*900mm
Light color：2200K / 3000K / 4000K / 6000K
LED chips：SMD3030 0.2W/led
Luminous flux(lm)：>280lm max
Remote control：Yes
Solar panel：6.2 Watts 5V
Battery capacity：3.2V 12AH 38.4WH
Battery lifetime：6,000 cycles @ D.O.D 80%
Motion sensor：PIR motion sensor
Discharge time：>36 hours





Datasheet

IK10 Rated Solar Bollard Light with Dual Direction LED Lighting Aluminum Body for High-End Residential Areas & Parks IP66 Rated



Solar Panel Mono, 25+years lifespan Material Aluminum+PC
Battery Life PO4, 6-8years Suitable for Outdoor lighting
LED chip High Brightness,10 years Working time 3-7 Rainy days
CCT. 3000-6500K Warranty 2-5 years
Waterproof  IP66 Level Motion sersor Yes
