Solar lighting industry's first military qualified enterprises
Home Products Integrated Solar Street Light

IP65 Waterproof Luminous Flux 10800Lm 30W-120W Outdoor Solar Street Light System

IP65 Waterproof Luminous Flux 10800Lm 30W-120W Outdoor Solar Street Light System

All In One Solar Street Light: Integrated Design/Free Maintenance/Easy Installation/Environmental Friendly.


  • Payment :

    T/T, Paypal, Western Union
  • Color :

    Silver
  • Lead Time :

    3~5 days for samples;15~20 days for bulk
  • Original Region :

    China
  • Port Of Dispatch :

    Qingdao
  • Infrared senor :

    Available
  • Battery Type :

    Lithium LiFePO4 Battery
  • Solar Panel Power :

    18V 90W
  • LED Power :

    60W
  • LED brand :

    LEADRAY
  • Model No. :

    LRC-H60W
Inquiry now


High temperature IP65 30W 40W 60W 80W 100W 120W Outdoor farola solar All In One Integrated led solar street light


Solar Street light poles for street lighting

images of street lights

all in one led solar street light

All In One Solar Street Light: Integrated design/Free maintenance/Easy installation/Environmental Friendly

Model No: LRC-H60W
Solar Panel Power: 18V 90W (High efficiency monocrystalline silicon)
Battery Type: High efficiency LiFePO4 Battery
LED Brand: PHILIPS
LED Power: 60W
Luminous Flux: 12000Lm(TYP)
Lifespan: 50,000hrs
Beam Angel: 150x70°
Charging Time: 6-8 hours
Lighting Time(Full Power): 12-14hours
Lighting Time(30% saving mode): 39 hours (3~5 rainy days)
Color temperature: 2700~6500K
Discharing temperature: -20 ℃ to +60 ℃
Charging Temperature: 0 ℃ to +60 ℃
Storage temperature: -20 ℃ to +45 ℃
Mounting Height: 6-8m
Suggested Distance Between Lights: 25-30m
Material: Superior aviation aluminum AL6063-T5

Warranty: 3-5 years


Physical Parameter
LED Brand PHILIPS PHILIPS PHILIPS PHILIPS PHILIPS PHILIPS
LED Qty(pcs) 72 108 144 256 256 384
Power of PV Module(W) 18V 60W 18V 70W 18V 90W 18V 110W 36V 120W 36V 160W
LiFePO4
Battery Capacity
12.8V 307.2Wh 12.8V 384Wh 12.8V 460.8Wh 12.8V 537.6Wh 25.6V 768Wh 25.6V 921.6Wh
Light Mode PIR/Time Control PIR/Time Control PIR/Time Control Time Control Time Control Time Control
Product Dimension(mm) 753*373*60 893*373*60 1123*373*60 1173*423*60 1413*423*60 1713*423*60
Product N.W.(kg) 12 14 17 22 24 32.8
Package #1 Dimension(mm)& G.W. (2 Lamps/CTN) 820*260*460 (20.7KG) 960*260*460 (24.2KG) 1190*260*460 (29.5KG) 1240*260*510 (37.5KG) 1480*330*510 (46.1KG) 1780*330*510 (50.85KG)
Package #2 Dimension(mm)& G.W. (2 Bases/CTN) 380*380*190 (7KG) 380*380*190 (7KG) 380*380*320 (10.93KG) 430*380*320 (10.93KG) 510*430*450 (20.85KG) 510*430*450 (20.85KG)
Light Parameter
Light Power(W) 30W 40W 60W 80W 100W 120W
Tyical Liminous
Flux(Lm)
5400 7200 10800 14400 18000 21600
LED Light E ect(Lm/W) 200Lm/W
Color Temperature(K) 2700-6500
Beam Angle(°) 150°x 80°
Rainy Days(D) 3~5
Environment Parameter
Charging
Temperaure( )
0 ~ +60
Discharging
Temperature( )
-20 to +60
Storage
Temperature( )
-20 to +45
Installations
Dia. of Top Pole (mm) 50~60 50~60 70~80 70~80 90~100 90~100
Installation Height(m) 4~6 5~7 6~8 8~10 9~11 10~12
Installation
Distance (m)
15~25 20~30 25~35 30~40 35~45 40~50

Application: street/roadway/parking lot/community/Industry park/playground

It will shift and turn on/off automactically

Application : street/roadway/parking lot/community/Industry park/playground

LRC-H Series LED Solar Street Light Features:

PRODUCT OVERVIEW
1. Up-to-day LED Technology with LED Modular Thermal Design.
2. Smart Battery Protection System, More stablequality and longer lifespan.
3. Modular Design,Battery can be drawn out easily .

4.Unique fluorescent decoration design (Color optional):Green / Red / Blue / Orange.


Integrated Battery Protection System
Military grade LiFePO4 Battery,High Safety and stability
Long lifespan, More than 2000 Battery light cycles
Secure metal structure around battery

Overcharge and over discharge protection


Super Bright LEDS

1.Up to date Super Bright LEDs, Lighting effect up to 210Lm/W.
2. Drive by low current, more energy efficient, Lighting efficiency increased by 40%.

3. Ultra-low light decay, lifespan up to 80,000 hours.


LED Modular System Design

1. Rectangular bat wing light distribution for road lighting Optimized light distribution for a more uniform and wider lighting area.
2. Integrated optical lens design, Light transmittance up to 93%.

3. Customized heat sink, better heat dissipation and waterproof ability.


Time Control

1.The lamp will stay on according to above metioned hours and lighting percentage (12H).

2.It will shift and turn on/off automactically.


High Brightness WIn One LED Solar Street Lightaterproof IP65 60watt All

Outdoor Aluminum Road Solar LED Street Lights

Integrated Battery Protection System

images of street lights



street/roadway/parking lot/community/Industry park/playground

To better ensure the safety of your goods, professional, environmentally friendly, convenient and efficient packaging services will be provided.



FAQ
Q1. Can I customize the light hours and brightness of the all in one LED solar street light product?

A1: Yes, our professional engineers will make the setting according to your requirements.


Q2. Can I have the all in one LED solar street light product without the sensor?

A2: Yes, All the LED solar street lights in all wattage can be made without the sensor, we will set timer-control for the lamps.


Q3. Can I use the all in one LED solar street light product on the islands?

A3: Yes, they are Anti-Tyhpoon/hurricane design with anti-rust treatment, which can be used in harsh environments such as islands, coasts, and lakeside.


Q4. Can I have a sample order for the all in one LED solar street light product?

A4: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.


Q5. What about the lead time?

A5: We could send sample for you within 7 working days, mass production time needs 1-2 weeks for order quantity more than 200pcs.


Q6: Do you offer guarantee for the products?

A6: Yes, we offer a standard 3-year warranty to our all in one LED solar street light product, a 5-year warranty is optional.


OEM & ODM Service
Brand, Logo,Color, Product Manual, Packaging etc....
18+ Years experience of Solar LED Lighting
Brand, Logo, Lighting mode, Brightness, Product Manual, Packaging, etc.
