  • Led solar street light
    80W Led Solar Street Lights High Lumen Motion Sensor Waterproof Integrated Road Street Lights

    Lamp Power:80-120W Solar Panel Power:110-160W Battery Capacity:538-691Wh PIR Motion Sensor Original Integrated concept, Double arc streamline Element Design; Innovative Battery Protection System; LED Modular Thermal Design; Typhoon Resistant。 CREE LED without gold wire packaging, creates a first-class light source; Rectangular beam design, with bat wing light distribution; 170Lm/W, 30% brighter than other similar products; Longer working hours, 15% longer than other similar products. The well optimized light distribution, made for a more uniform and wider lighting area; Lens with exhaust valve, prevent water vapor gathered & makes longer lifespan; Original thermal system design, innovative heat sink with IP67 PG head.

  • Led solar street light
    solar street light 80w led aviation aluminum Integrated All In One LED street light solar waterproof outdoor

    Place of Origin: Shandong, China Brand Name: Leadray Model Number: LRC-I80W Application: Roadway Color Temperature(CCT): 2700 -6500K IP Rating: IP65 Beam Angle(°): 150x80° CRI (Ra>): 75 Input Voltage(V): DC 12V Lamp Luminous Efficiency(lm/w): 210 Lamp Luminous Flux(lm): 12800Lm(TYP) Warranty(Year): 3-Year Working Temperature(℃): -20 - 60 Color Rendering Index(Ra): 80 Certification: EMC, RoHS, FCC, LVD, SASO, CE Power Supply: Solar powered Light Source: LED Support Dimmer: Yes Lighting solutions service: Lighting hours and brightness adjustable Lifespan (hours): 50,000hrs Working Time (hours): 12-14hours each day Product Weight(kg): 12 Product name: 80W Integrated Solar LED Street Light Battery Type: Lithium LiFePO4 battery Light Mode: Timer Control Solar Panel Lifespan: 25 years Charge Time By Strong Sunshine: 6-8 hours LED Source Max Power: 24V 80W Material: Superior aviation aluminum AL6063-T5 Solar Panel Max Power: 90W Lighting Time 30% saving mode: 39 hours (3~5 rainy days) Product: 1589.5*258*65mm

  • Led solar street light
    Leadray PIR Sensor Smart Outdoor Lights Waterproof Ip65 40w APP Remote Control Motion Sensor Bright Solar Led Street Lamp Light

    Place of Origin: Shandong, China Brand Name: Leadray Model Number: LRC-I40W Application: Roadway Color Temperature(CCT): 2700 -6500K IP Rating: IP65 Beam Angle(°): 150x80° CRI (Ra>): 75 Input Voltage(V): DC 12V Lamp Luminous Efficiency(lm/w): 210 Lamp Luminous Flux(lm): 6400Lm Warranty(Year): 3-Year Working Temperature(℃): -20 - 60 Color Rendering Index(Ra): 80 Certification: EMC, RoHS, FCC, LVD, SASO, CE Power Supply: Solar powered Light Source: LED Support Dimmer: Yes Lighting solutions service: Lighting hours and brightness adjustable Lifespan (hours): 50,000hrs Working Time (hours): 12-14hours each day Product Weight(kg): 18 Product name: 30w Integrated Solar LED Street Light Battery Type: Lithium LiFePO4 battery Light Mode: PIR Motion Sensor Solar Panel Lifespan: 25 years Charge Time By Strong Sunshine: 6-8 hours LED Source Max Power: 12V 40W Material: Superior aviation aluminum AL6063-T5 Solar Panel Max Power: 60W Lighting Time 30% saving mode: 39 hours (3~5 rainy days) Product: 999.5*258*65mm

  • Led solar street light
    80W Energy Saving Outdoor 30W 40W 60W 100W 120W All In One Solar Power Led Street

    New design Ip65 100W Outdoor All In One Solar Street Lamp 60W 80W 100W 120W Integrated Led Solar Street Light. 1.Modular design,easy maintenance 2.Up to 210Lm/W,with optical design 3.Battery protection &heat dissipation design 4.Smart control management system Lighting Model:Timer Control: 1hrs 30% lighting + 2hrs 100% lighting + 2hrs 50% lighting + 7hrs 20% lighting =12hours

solar light
Products
20W Solar All In One Street Light
20W Solar All In One Street Light with Pole High Brightness Outdoor Ip65 Waterproof Solar Street Light 20W Solar All In One Street Light with Pole High Brightness Outdoor Ip65 Waterproof Solar Street Light 20W Solar All In One Street Light with Pole High Brightness Outdoor Ip65 Waterproof Solar Street Light 20W Solar All In One Street Light with Pole High Brightness Outdoor Ip65 Waterproof Solar Street Light 20W Solar All In One Street Light with Pole High Brightness Outdoor Ip65 Waterproof Solar Street Light 20W Solar All In One Street Light with Pole High Brightness Outdoor Ip65 Waterproof Solar Street Light
20W Solar All In One Street Light with Pole High Brightness Outdoor Ip65 Waterproof Solar Street Light
  • Model No. :

    LRC20W
  • LED brand :

    LEADRAY
  • LED Power :

    20W
  • Solar Panel Power :

    18V 40W
  • Battery Type :

    Lithium LiFePO4 battery
  • Infrared senor :

    Available
  • Color :

    Silver
  • Port Of Dispatch :

    Qingdao
  • Payment :

    T/T, Paypal, Western Union
  • Original Region :

    China
  • Lead Time :

    3~5 days for samples;15~20 days for bulk
Contact Us
description
20W Solar All In One Street Light

20W Solar All In One Street Light: Integrated Design/Free Maintenance/Easy Installation/Environmental Friendly.

Solar LED Street Light with PIR Motion Sensor High Brightness Outdoor Ip65

All In One Street Light
Model No: LRC20W
Solar Panel Power: 18V 40W (High efficiency monocrystalline silicon)
Battery Type: High efficiency LiFePO4 Battery
LED Brand: CREE
LED Power: 20W
Luminous Flux: 2800Lm(TYP)
Lifespan: 50,000hrs
Beam Angel: 150x70°
Charging Time: 6-8 hours
Lighting Time(Full Power): 12-14hours
Lighting Time(30% saving mode): 39 hours (3~5 rainy days)
Color temperature: 2700~6500K
Discharging temperature: -20 ℃ to +60 ℃
Charging Temperature: 0 ℃ to +60 ℃
Storage temperature: -20 ℃ to +45 ℃
Mounting Height: 4-6m
Suggested Distance Between Lights: 18-20m
Material: Superior aviation aluminum AL6063-T5

Warranty: 3-5 years

Model No. LRC20W
Physical Parameters
LED Brand CREE
LED Qty 18
Power of PV Module (W) 40W
LIFEPO4 Battery Capacity (Ah) 18
PIR Sensor YES
Dimension of Product (mm) 908*281*56
Net Weight (kg) 13
Dimension of Carton (mm) 980*350*260
Gross Weight (kg) 14.5
Light Parameters
Light Output (W) 20W
Typical Luminous Flux (Lm) 2800
Color Temperature (K) 2700-6500
Beam Angle (°) 150°x70°
Min. Working Time  (Hours) Full Bright 13
Dim Mode 39
Environment Parameters
Charging Temperature (°C) 0 °C to +60 °C
Discharing temperature (°C) -20 °C to +60 °C
Storage temperature (°C) -20 °C to +45 °C
Installation
Recommended Dia. of Top Pole (mm) 60~105
Recommended Installation Height (m) 4~6
Recommended Installation Distance (m) 18~20

Solar LED Street Light with PIR Motion Sensor High Brightness Outdoor Ip65


Solar LED Street Light with PIR Motion Sensor High Brightness Outdoor Ip65

Solar LED Street Light with PIR Motion Sensor High Brightness Outdoor Ip65


Cree® XLamp® XT-E LEDs

CREE LED without gold wire packaging, creates a first-class light source

140Lm/W, 30% brighter than other similar products

Longer working hours, 15% longer than other



Innovative Battery Protection System

Built-in LiFePO4 class A battery, single cell with PTC Over charging & over discharging protection




Original separate design with 5mm gap between battery and solar panel




Air convection & thermal system design, More air flows and better heat dissipation

Solar LED Street Light with PIR Motion Sensor High Brightness Outdoor Ip65
